Basic VCO

Tune control: coarse and fine
2 CV inputs for pitch modulation
1 CV level control for pitch modulation
Pulse width adjustable
1 CV input for pulse width modulation (PWM)
1 CV level control for pulse width modulation (PWM)
Outputs saw and pulse simultaneously
3mm face plate
Power requirements: +/-15V
curetronic and power connector

  • ? mA +15V
  • ? mA -15V
  • ? mA 5V

This Module is currently available.

1 HP Oscillator
