2 HP
Current Draw
? mA +15V
? mA -15V
? mA 5V

This Module is currently available.

Synthesis Technology MOTM 480 CS-80 Filter

Unlisted FilterMixer

CS-80 Resonant Filter

The MOTM-480 VCF is configured as a super-bandpass filter with independent corner frequencies and resonant peaks, similar to the configuration of the legendary Yamaha CS-80. This module can create distinctive pad and brass timbres. The built-in audio mixer can filter any audio source. An expansion connector is included for future configurations.

*Dual resonant state-variable VCF with characteristics specific to the CS-80

*Cascaded HP & LP filters with lowpass (LP) and bandpass (BP) outputs

*Independent voltage-controlled frequency and resonance

*Three audio inputs with individual level controls


submitted Mar 29th 2021, 23:05 by Precarious | last Change Mar 29th 2021, 23:06 by Precarious
