Dimensions
2 U
Current Draw
? mA +15V
? mA -15V
? mA 5V
Price

This Module is a prototype or in a concept phase.

Dual-output EG and LFO - CUSTOM

The world's most advanced ADSR. Features 3 different EG models: 911 style DADSR/AHDSR, Synthi 100 Trapezoid with quadrature outputs, and our own ADSAR/DASAR we call the Pyramid Blaster. If it's confusing why there are multiple shapes mentioned for each model, it is because this envelope generator outputs two shapes simultaneously!

There are 4 modes of operation: Hold, Trigger, LFO A and LFO B. "Hold" means the envelope will move to the sustain stage and wait until the trigger input returns to 0V to move to the next stage. "Trigger" means the envelope will move through all time stages on a leading edge at the trigger input, "LFO A" means the envelope will free-run in a loop and restart on a leading edge at the trigger input, and "LFO B" means it will loop only while a gate signal is present at the trigger input.

Envelope Generator has 4 different time scales: X.1, X1, X10, and Tempo Sync. The Xn scales are based on the absolute time markings on the front panel dials, 1 second, 10 second, and 100 second ranges. "Sync" will tempo syncronise the stage times to musical values based on tempo information received over the STG Clock Bus connector on the back of the unit.

Additionally the module supports full voltage control of time and sustain level, slope control and cv, and gate outputs for each stage via a sidecar module.

http://stgsoundlabs.com/products/envelope_generator_mu.htm


submitted Jul 5th 2020, 06:14 by sugarfree | last Change Oct 10th 2020, 20:51 by sugarfree
