Shuffling Clock Multiplier V1

SCM: Clock Multiplier, Shuffler and rhythmic pattern generator

The Shuffling Clock Multiplier (SCM) produces eight multiplied clock tempos from a single input clock, ranging from x1 to x8 (x32 by using the Breakout). Some of the outputs can be shuffled/swung. The amount of shuffle is controlled by a CV Slip jack. A Rotate CV jack re-assigns the multiplication number of each jack. More features of the SCM can be controlled by the SCM Breakout.

Power consumption on +12V rail can be reduced from 33mA to 19mA by setting jumper to use 5V rail (which will draw 14mA on the 5V rail)

http://4mspedals.com/scm.php

  • 33 mA +12V
  • 4 mA -12V
  • 0 mA 5V
  • 48 mm deep
  • Ø 4.07 (15 Votes) Average Rating

Module is available as a DIY project only.

This Module is currently available.

$179 Price in € submitted Oct 13th 2012, 00:22 by 4ms_Company | last Change Jan 3rd, 20:57 by 4ms_Company
Specs are approved by the manufacturer
