ADDAC802 Quintet Mixing Console

Reversed Panel for ADDAC802

Features:
2 independent mixing channels, Solo and Mix
Mix Output includes a 6th VCA with Pre and Post outputs

5 independent VCA's with:
Independent outputs
Linear or logarithmic control
Solo/Off/Mix switch that routes their audio to the Solo Channel or the Mix channel. In Off position the VCA does not go to the outputs. This way you can use all 5 VCA's separately for different sources (audio or cv) or mix in 2 different chains.
The Solo line is also intended for Pre Listening purposes, using this output to connect your headphones through some headphone amplifier module.

External input into the Mix channel for daisy chaining.

http://addacsystem.com/product/addac802-vc-mixer

  • 150 mA +12V
  • 150 mA -12V
  • ? mA 5V
  • 55 mm deep
  • Ø 5.00 (2 Votes) Average Rating

This Module is currently available.

$350 Price in €
Unlisted 12 HP MixerVCA
