MS-812 companion product

The MS-4 is a ideal companion product for one or several MS-812.
A MIDI input brings versatility for stage or computer-less setups.
Direct control knobs give access to live settings while CV inputs allow dynamic modulation of parameters.

Features :
Controls up to 8 MS-812 (automatically detected)
32 presets storage in flash memory, recalable by MIDI
Each of the 16 incoming MIDI channels can be directed to mono, poly and drum sections in any MS-812
In each target section, the MIDI and the network data are merged automatically
The MIDI clock can be sent to one or more MS-812
Direct access to monitor and edit the MS-812's voicing mode, portamento duration, and two freely defined parameters.
Four CV inputs with editable range, polarity and offset can be sent to any MS-812 parameter to be modulated in real time (e.g portamento time, comparator, ...)
Advanced routing and editing is possible via the CP Manager freeware application
Knobs and CV can be sent to any CopperLan or MIDI (CC) destination.

  • 90 mA +12V
  • 2 mA -12V
  • 0 mA 5V

This Module is discontinued.
