Dual Full Wave Rectifier (1U tile)

Dual Full Wave Rectifier racked as a 1U tile

This is an all analog synthesizer module used to alter the timbre and create new harmonic content. It consists of two identical full-wave rectification circuits, which can be used seperately or one cascading into the other. Each circuit has a manual bias offset as well as external CV that can be used to offset the bias.

The board features PC mounted pots for less wiring, and mounting holes for flexibility in panel layout. There are Eurorack and MOTM power connecters.

https://www.bartonmusicalcircuits.com/fwd/

18 mA +12V
18 mA -12V
0 mA 5V
45 mm deep
Ø 4.75 (4 Votes) Average Rating
