analog sensor calibration module

SENSE can convert and amplify signal from almost any type of analog sensor into control voltage and gate signals. You can use sensors with variable resistance (light dependent resistors, body contacts, water contacts etc.) or sensors that already output voltage (pulse sensor, accelerometer, inductors, piezo etc.) amplify them and calibrate them in the way to have suitable control voltage and gate output signals.

Features

voltage or resistance input
pinheader patchbay for connecting sensor
resistance range switch
pre-amp for voltage sensors
gain knob with clipping indication
voltage offset (positive or negative)
AC or DC coupling for amplification
threshold for gates
CV output and inverted CV output
GATE output and inverted GATE output

PTC fuse and diode protected 16pin power connector
requires 5V in the bus

Correction to Manufacturer Specs: although the website STATES 5V is needed / 16-pin connection, the ribbon connection is 10-pin header (i.e. actual module doesn't actually connect to the 5V rail)

http://noise.kitchen/shop/bastl/bastl-instruments-sense/

  • 35 mA +12V
  • 25 mA -12V
  • 0 mA 5V
  • 50 mm deep
  • Ø 5.00 (1 Votes) Average Rating

This Module is currently available.

$112
5 HP Controller
