Dimensions
10 HP
25 mm deep
Current Draw
48 mA +12V
18 mA -12V
0 mA 5V
Price
$116 Price in €

This Module is currently available.

Specs are approved by the manufacturer

fading cv modulator

The FADE gives a solution to control CV’s in your system from a central place in your system. Next to that it gave an answer to the problem that very complex modules sometimes have functions which are only accessible through either menu diving or – there it is – an external CV signal.

This module sends out a CV signal by means of sliding one of the faders. There are 4x high quality 60mm faders in 10hp – and we chose faders with a LED indicator to give an indication on how high the output approximately is.

The range of the CV out is adjustable by jumper settings on the back (0V, -5V, +5V and +10V are available). The black lines on the backside clearly indicate which jumpers belong to which fader. Remember that this is the backside of the module so the order of the faders is reversed.

This module is made in collaboration with Studio am Rhein.

  • Power consumption 12v 48mA; -12v 18mA; 5v 0mA

* includes cable and M3 screws

https://www.etsy.com/listing/1143754131/fade-eurorack-cv-modulator
