Dimensions
8 HP
25 mm deep
Current Draw
9 mA +12V
9 mA -12V
? mA 5V
Price
$110 Price in €

Available as an assembled Module and as a DIY project.

This Module is currently available.

Specs are approved by the manufacturer

Dual Audio VCA

  • size: 8hp

  • single Thru-Hole PCB design

  • 10 pin eurorack power connection

The CubuSynth Dual Vintage VCA is a nice sounding, zero bleed, analog Voltage controlled amplifier based on the
LM13700 Dual OTA. It can work as two independent VCAs or as a stereo unit, and CV input 1 on channel 1 is normalized to
the CV input 1 on channel 2. (same signal can control both Channels)
The Original concept is designed by Tom Wiltshire aka "Electric Druid". For more information visit:
https://electricdruid.net/design-a-eurorack-vintage-vca-with-the-lm13700/

1 LEVEL
Sets the Amplitude for each channel.

2 CV AMOUNT
Attenuates the Control voltage from CV input (3)

3 CV
CV input for the amplitude Modulation. The input on channel 2 is
normalized from CV on channel 1 when nothing is plugged in.

4 CV2
A second CV input for amplitude modulation, without attenuator

5 IN
Input for Audio Signal

6 OUT
Output for the Audio Signal

BOM / Build documents:

https://github.com/CubuSynth/Dual-Vintage-VCA-doc

https://cubusynth.com/products/cubusynth-dual-vintage-vca
