Dimensions
6 HP
30 mm deep
Current Draw
55 mA +12V
15 mA -12V
0 mA 5V
Price
$209 Price in €

This Module is currently available.

Specs are approved by the manufacturer

3 channel preset manager / multistage and macro controller

BABY, YOU MAKE ME WISH I HAD THREE HANDS!

6 HP width, 3x CV preset manager/multistage and macro controller for Eurorack
3 channel control voltage generator/attenuator/attenuverter
8 preset CV manager with two banks: bipolar -5...+5V and unipolar 0...+5V
Instant, slewed or continuous change between stored CV values
3-channel macro CV generator with smooth min./max. control via CV, trigger or manually
CV acquisition: 16 bits SDADCs, CV outputs: 12 bits DACs
Depth: 30 mm (with plugged ribbon cable)
Power requirements: +12V: 55mA, -12V: 15mA


submitted Jan 9th, 13:42 by Endorphines | last Change Jan 14th, 15:28 by Endorphines
