Dimensions
8 HP
Current Draw
10 mA +12V
10 mA -12V
0 mA 5V
Price
$222 Price in €

This Module is currently available.

Serge-eske Jenny

The Swoop module is essentially a bound/bounce control voltage processor, in the lineage of such multi-purpose tools as the “Serge Dual Universal Slope Generator”. Like that module, Swoop responds to:

  • Input voltages that set target boundaries in voltage
  • Control voltages for angle of both the down and up segments of the waveform
  • Trigger voltages that perform a single “swoop” up or down.

It differs, however from the DUSG, in that it truly is a free-running oscillator, that will bounce between any given boundaries; bounds take a more correlative role in deciding the frequency. In fact, it is already running when given zero input, bouncing infinitesimally at a very high resultant frequency.

This oscillator was conceived as a sort of triangular answer to the operation of filters, that take an input and resonate damp. Damping, in Swoop, results in an ever higher and higher frequency, thus fulfilling the bounds/bounce concept. Inspired by the idea of polarity, there are actually two triggers, for upward swoop and downward swoop, or even both ways consecutively.

Swoop is an 8HP Eurorack module that runs on +12 and -12 volts. Attach power connector positive to “+” and negative to “-”. Failure to follow proper power polarity will result in instant destruction of unit.

Manual: https://www.ciat-lonbarde.net/ifm/ifmSWO.pdf

http://synthmall.com/ifm/index.html


Ø 4.36 (11 Votes) Average Rating
submitted Sep 1st 2014, 07:16 by Ginko | last Change Dec 10th 2023, 10:01 by tokkel8r

48 Users are observing this
