Clock

Clock is a free-running master clock and a switchable divider. Dual tempo knobs give you coarse and fine control. Master on-off switch is a vital feature.

The ComplexClock is a free-running master clock and a switchable divider. Dual tempo knobs give you coarse and fine control. Master on-off switch is a vital feature.

The jack at the top is an input so you can be sync’ed to another master clock and use the divider. If you want voltage control over the tempo, you’d input that here from an LFO or a VCO. There’s a discrete Schmitt Trigger so you can use a soft triangle and it becomes a hard square, to better serve the dividers.

The internals are analog, so the divider will run at audio rate if you want to use them as a sub-oscillator.

The four outputs are progressively slower divisions: x2 is a halving, then the last two are controlled by the switches to be thirds or fifths, and half that. With both switches up, you get the fastest divisions: 1x,2x,3x,6x. With both switches down, you get the slowest divisions: 1x,2x,10x,20x.
