Dimensions
10 HP
50 mm deep
Current Draw
50 mA +12V
? mA -12V
? mA 5V
Price
$238 Price in €

This Module is currently available.

Frequency Shifter (Needs Modulator)

  1. Hilbert Transformation Filter for incoming signal, DOM fitler (B. Hutchings, Haible)

  2. Two precision multiplier for sin / cosin transformation (AD633) Mixer for up- down shifts, balance between Ring modulation and Single Sideband Supression.

  3. For work you need a quadrature VCO. A Doepfer A110-4 is perfect it produce sine and cosine wave, or a state variable filter is also possible (s/csine at LP/HP).

The RMO knob allows continus shift between ringmoduation (only one multiplier) to single side band supression. You can creat interest sound inbetween and enables you to tune exact SSS balance for your signal. The intupt mixer allows you to insert a digitaldelay for delayed shifts.

Moduations VCO: For up or down shifts the phase must be inverted. Doepfers A110-4 produces sine/cosine and shifts phase with LFrq poti. Modulation for LinFrq and XFM for extraordinary shift sounds get possible. Basic desing of A110-4 was intended to use in FS-systems (H. Walmsley).
