BoardPWR

BoardPWR is a small and low weight synth PSU solution. You can mount it into your synth case without sacrificing any additional HP.

BoardPWR is a small and low weight synth PSU solution. You can mount it into your synth case without sacrificing any HP. If you are looking for a high-quality low noise power supply for your modular synth, you found it. BoardPWR delivers 12V / 2A, -12V / 1.2A and +5V/1.5A. With its small footprint, BoardPWR is a perfect PSU solution for the ever traveling musician. BoardPWR is safely supplied from an external DC power brick (16-20V). It is possible to chain more BoardPWRs together in one case and feed them from one power brick altogether. There are two types of output connections. You can either connect bus boards via two 16pins IDC headers (ideal for flying bus boards) or via high-quality WAGO spring terminals. We recommend Meanwell GSM60A18-P1J DC Power Brick for one BoardPWR PSU and GST120A20-P1M for two BoardPWR PSU solutions.

Designed, manufactured, and assembled by hand at Konstant Lab - Slovakia / EU.
http://konstantlab.audio/
https://www.facebook.com/konstantlab
https://www.instagram.com/konstantlab/

Technical parameters:

Power:
45W

Width:
0 HP :) - internal PSU solution for you modular system

Outputs:
+ 12V / 2A
- 12V / 1.2A
+ 5V / 1.5A

Output stability:
± 1% for 0-100% load

Input:
18V ( 16V - 20V) - recommended power brick: Mean Well GSM60A18

Dimensions:
100 × 45 × 20 mm

Weight:
127g

Output Connectors:
2x 16 pin IDC for flat cable
4x WAGO spring terminals

Input connectors:
WAGO spring terminals
Panel with 5,5 x 2.1 DC input (center positive) and switch included

Protections:
Input filter
Input over voltage
Input reverse polarity
Output over voltage
Output short current – automatic recovery
Output over current – automatic recovery
All output protections are independent for each rail

Efficiency:
92%

Other:
Input common mode LC filter with high efficiency of canceling noise and interference from input connector
Additional input filter on each regulator for minimal output noise and interferences
LEDs indicate present and drop of output voltage

Accessories:
Alluminum panel with 5,5 x 2.1 DC input (center positive), power switch and two 25cm wires
Screws 2,9 x 13mm 4pcs
Spacers 3mm height 4pcs
