Dimensions
8 HP
48 mm deep
Current Draw
30 mA +12V
30 mA -12V
0 mA 5V
Price
$114 Price in €

No info about availability.

O-110 VCO1

VCO

O-110 VCO1 (8HP) voltage controlled oscillator, triangle/square core, range about 3Hz to 25kHz, temperature compensated.

Left column: coarse and fine tuning, lin FM knob & jack, CV1&2 inputs (CV1 for exact tuning, CV2 for log FM), square output

Right column: initial pulse width & saw shape, PWM/saw animation amount knob, PWM/saw shape jack. Triangle, sine, saw and pulse width outputs

http://ladik.ladik.eu/?page_id=699


Ø 4.67 (3 Votes) Average Rating
