(DUPLICATE) Distribution, input, output, multiple

Real listing: https://www.modulargrid.net/e/make-noise-cv-bus

The CV Bus was originally designed for Alessandro Cortini's personal Make Noise system. It provides visual indication of level, rate and polarity for up to 4 control signals that will be shared throughout a patch. These 4 control signals are color coded and distributed across the center of the system allowing for quick, clean and intuitive patching. The distribution method is unlike the typical multiple since the control signals will appear beneath their possible destinations allowing for the use of shorter patch cables. The color coding and visual indication makes navigating complex patches easier and more intuitive. Typically, the CV Bus would be used to share the most important control signals in a patch such as your Master Clock.

The CV Bus also has the tools needed for integrating the Make Noise system with the outside world. A 1/4" Mono input with plenty of gain allows for bringing external signals into the system. The optimal 10Vpp signal level is visually indicated. A high quality Stereo Line Driver converts powerful modular synthesizer signal levels to the commonly used Line Level. There is mini-jack inputs for Left and Right, a single Master Volume control, and a TRS Stereo 1/4" output jack. This output is capable of driving long cable out to a PA System or a set of Headphones. It has AC coupling and a built-in limiting circuit (with visual indication) that prevents damage to ears and PA system when the patching gets experimental.

http://makenoisemusic.com/cases/7u-steel-cv-bus-case-matte-black

  • 41 mA +12V
  • 36 mA -12V
  • 0 mA 5V
  • Ø 5.00 (3 Votes) Average Rating

This Module is currently available.

Module is a 1U tile.

$660 Price in €
Unlisted 104 HP MultiplePreAmp
submitted Dec 17th 2017, 17:39 by JohnnyVonHifi | last Change May 20th, 01:07 by exper

4 Users are observing this
