Dimensions
8 HP
Current Draw
6 mA +12V
? mA -12V
? mA 5V
Price
$150 Price in €

Available as an assembled Module and as a DIY project.

No info about availability.

Mixer with headphone amplifier section

Simple and super useful mixer and line level output with added headphone monitor.

Inputs

  • 3x Mixer in : Signals in to mix
  • Phones in : Audio to monitor on headphones

Outputs

  • Phones : Headphone output from phones in for live queuing of patches. Is normalled to the mix out if nothing is plugged into phones in
  • Mix Out : Eurorack level mix from the 3x mixer in
  • 1/4" Out : Line level out for sending to an amp or similar

Knobs

  • 3x input attenuator
  • Phones input attenuator

Modifications

  • Normal Phones in to main mix
  • Normal main mix to phones out

Tips/Tricks

You can use the phones in/out as an attenuator for audio or CV. I've found you can even boost the level slightly. This can come in handy for patching external audio sources into your modular.

https://www.nonlinearcircuits.com/modules/mixer


Ø 4.00 (5 Votes) Average Rating
submitted Dec 6th 2014, 15:55 by jsleeio | last Change Sep 6th 2021, 12:37 by westkraut

2 Users are observing this
