Clock Breakout

Clock/Run breakout I/O

Breaks out Clock and Run for Input and Output to 3.5mm TRS cables (e.g. Beatstep Pro).
Features a sticker for my buddy's skate brand, Old Dude Skate Co. http://olddudeskateco.com/

NOTE: Breakout cables route to back of panel, so need an egress point out of the case if going to external gear.
This build wires the 3.5mm jack to RCA jacks because I had them on hand. However they are REALLY deep and awkward, so will probably get replaced.
Cables are (one eace for input and output) common 3.5mm TRS Male to 2-RCA Male Y cables. E.g. https://www.amazon.com/Mediabridge-3-5mm-Male-2-Male-Adapter/dp/B004YEBK66

  • Module does not draw current
  • 45 mm deep

Module is available as a DIY project only.

This Module is a prototype or in a concept phase.

$2 Price in €
4 HP Utility
