Control Voltage Processor

Control Voltage Processor = 3x Attenuverter+Slew+Offset + Mixer

This is a DIY Control Voltage Processor inspired by the Manhattan Analog CVP
with 3x Attenuverter + Slew + Offset per collumn + Mixer with inverted and non-inverted Out.

The current draw is about 60mA +12V and 60mA -12V

  • 60 mA +12V
  • 60 mA -12V
  • ? mA 5V
  • 50 mm deep
  • Ø 5.00 (1 Votes) Average Rating

Module is available as a DIY project only.

No info about availability.

submitted Jul 16th 2014, 21:59 by Jojo | last Change Jul 21st 2014, 11:11 by Jojo
