Dimensions
4 HP
39 mm deep
Current Draw
Module does not draw current
Price
$20 Price in €

Module is available as a DIY project only.

This Module is a prototype or in a concept phase.

DIY Passive Multiple "Backdoor"

Unlisted ExternalMultiple

Passive Multiple with rear facing jacks on the back

This DIY passive multiple functions just like most multiples with one twist. It has two rear facing jacks that allow the inputs of the top input jack of each group to be routed internally. One use of this is to route the signal from the inputs to an oscilloscope while still multiplying the signal to the other jacks in the group.


submitted Aug 11th 2017, 12:53 by FileTransferProtocol
