HAGIWO 6-Ch Euclidean Rhythm / Random Sequencer

HAGIWO 6 Channel Sequencer / Euclidean Rhythm Sequencer

This is a through hole PCB version of the awesome HAGIWO 009 and HAGIWO 030 eurorack synth modules made an published on Github by Testbild-synth

The module runs on an Arduino Nano and can run two different Firmware flavors:

• six channel drum sequencer (six_channel_sequencer.ino)
• euclidean sequencer (euclid_sequencer.ino)

Hardware features are:

• 128*64 OLED Display
• Rotary Encoder with PUSH Button
• 6x Trigger Output (0-5V)
• Clock Input (0-5V)

DIY Info:

Building the Module is straigt forward and suited for beginners. Only 25 common Parts in total.

Find more Info and Assembly Instructions, Code, BOM check the repository here: https://github.com/Testbild-synth/Hagiwo_009_030_sequencer

HAGIWO original Articles are here:

HAGIWO 009 and here HAGIWO 030.

VIDEOS:

• HAGIWO 009

• HAGIWO 030

https://github.com/Testbild-synth/Hagiwo_009_030_sequencer
