Dimensions
4 HP
20 mm deep
Current Draw
12 mA +12V
12 mA -12V
0 mA 5V
Price

This Module is currently available.

Two buffered multiple 1 to 3 with signal status LEDs.

  • Two 1 to 3 or 1 to 6 multiple.
  • Suitable for clock, CV and audio signals.
  • Bi-color led for indicate input signal.
  • Diode protection on reversed power supply.
  • CNC milling front panel (2 mm FR-4 or aluminum front panel option).
  • Handcrafted in Russia.

Link to flowchart:
https://pp.userapi.com/c844216/v844216340/76aa4/uWmhMhdQIQc.jpg


submitted Mar 8th 2018, 18:17 by White_Noise_Custom | last Change Jun 10th 2018, 17:44 by White_Noise_Custom
