Dimensions
2 HP
10 mm deep
Current Draw
Module does not draw current
Price
$15 Price in €

Module is available as a DIY project only.

This Module is currently available.

a simple passive stereo output

Most of the stereo outs on the market are quite large and with a nearness you can quickly create a large stereo field. Having the extra pan knobs on most stereo outs tends to be irrelevant when using nearness (well, less relevant). The new ALM output looks good, but I wanted to put together a super-duper easy DIY kit. This thing is totally passive & so simple, there aren’t even any resistors! here is the BOM:
a PCB
a panel
2 mono thonkiconn jacks
2 9mm tall trimmer pots
1 stereo thonkiconn jack

Each channel’s volume needs to be controlled independently, but this means it can also be used as a single mono attenuator good for audio or CV on the left channel.

More info and discussion here: https://llllllll.co/t/2hp-passive-stereo-output-a-companion-for-nearness/14189

DIY files here: https://github.com/bmoren/Stereo-Output-2hp
