SWT

P4L / SWT

SWT is a simple utility module with two 3IN/1OUT routing selectors.

A manually operated 3-way switch allows you to switch which of the three inputs is output and can be used as a routing selector for audio/CV/GATE and other signals.
The three input jacks correspond to the top, middle and bottom of the toggle switch, and the signal in the selected position is output from the OUTPUT jack circled in white.
As this is passive, this can also be used as a 1IN/3OUT OUTPUT selector by connecting the IN/OUT in reverse.
