VCA-01

Three voltage controlled discrete amplifiers.

  • Manual BIAS control for each VCAs.
  • CV control with attenuator for each VCAs. CV input C normalled to CV input B, CV input B normalled to CV input A.
  • Independent CV control (without attenuator) for A and C VCAs.
  • Bi-color led for indicate input CV signal for each VCAs.
  • Out signal from VCA A and VCA B always mixing (A+B out).
  • Input C normalled to A+B out.
  • Diode protection on reversed power supply.
  • CNC milling front panel (2 mm FR-4 or aluminum front panel option).
  • Handcrafted in Russia.
    Function diagram here.

  • 50 mA +12V
  • 45 mA -12V
  • 0 mA 5V
  • 38 mm deep

This Module is currently available.

10 HP VCAMixer
