Dimensions
16 HP
16 mm deep
Current Draw
54 mA +12V
50 mA -12V
0 mA 5V
Price

No info about availability.

VCF74 Rev-A

Unlisted Filter

VCF clone of 1970s Mini-Korg (Rev-A prototype)

The VCF74 is an enhanced version of the 1970s Mini-Korg 700/700s filter circuit, a.k.a. "traveller". It has independent high-pass and low-pass filters with CV inputs. CVs for the filters can be controlled via a variable gain/attenuation stage. The input and output audio paths also have independent gain controls. Additionally, there is a variable resonance and brightness control. Note that Rev-A (prototype only) does not have a CV for resonance, although plans for a CV controlled resonance are going to be implemented in the Rev-B model.


Ø 5.00 (2 Votes) Average Rating
submitted Nov 27th 2015, 19:47 by vintagesynthlab | last Change Sep 26th 2016, 23:00 by vintagesynthlab
