Dimensions
4 HP
30 mm deep
Current Draw
? mA +12V
? mA -12V
? mA 5V
Price

Module is available as a DIY project only.

This Module is a prototype or in a concept phase.

Clock source with MIDI input and clock divider outputs

Xtal is a clock source with multiple outputs capable of synchronizing
to a MIDI clock or generating it's own.

Overview

Hardware

  • Eurorack 4U Format
  • STM32F030K6 ARM Cortex M0 MCU
  • 1 Potentiometer
  • 4 3.5mm Gate Outputs
  • 1 3.5mm TRS MIDI Input (Arturia-style)

https://github.com/kleinpa/xtal


submitted Sep 18th 2017, 01:58 by kleinpa | last Change Jan 27th 2020, 23:51 by kleinpa
