Punch v2

Compact Dual VCA designed for percussive sounds

Punch is the ultimate VCA-DECAY module for Eurorack – specially designed to generate dynamic percussive sounds but also capable of basslines, leads, envelopes and more. The VCA has a built in voltage controlled Decay envelope that can be turned from smooth to more aggressive logarithmic responses and can be activated with triggers, gates or cv’s. Punch also features accent inputs on each channel, for more interesting and dynamic sounds and envelopes. Each envelope can also be inverted via dedicated switches on the front panel. If you use an inverted envelope alongside the accent input you can create ducking effects like side-chain compression.

Features:

Dual VCA with voltage controlled Decay.
Adjustable Decay curve
Snappy attack ideal for percussion
Accent inputs
Envelope shape invert switches
Width: 9HP
Skiff friendly
Power consumption: 52mA@+12V, 50mA@-12V
