A/B++ (white panel)

A/B switch - patchbay - multiple

(For the presentation, all leds are visible by photo editing because in reality, leds A & B can not be activated at the same time)

The A / B ++ module is an utility that combines several functions into two independent parts:
In the upper part, a passive A / B switch (comparator):

alt text

alt text

At the bottom, a patchbay / multiple (also passive).
alt text

alt text

alt text

And a passive multiple (see manual)

  • Multifonction module
  • Independent LED circuit to avoid signal disturbance or voltage drop
  • Black or White panel...
  • Skiff friendly

The price includes: module, screw M3 and connection cable. Excluding shipping costs !!
Manufactured by ph Neutre
Available as an assembled Module, no kit.

Also available in black panel :
alt text

To order, please contact me (phneutre56@gmail.com) the terms of payment, delivery times and shipping costs, will be detailed by return mail.
The payment will be in euros (€) and can be done by paypal. Delivery possible in the world, please contact me (phneutre56@gmail.com)
Shipping costs :
alt text

http://ph.neutre.free.fr/AB_En.htm

  • 9 mA +12V
  • 0 mA -12V
  • 0 mA 5V
  • 25 mm deep

This Module is currently available.

$61 Price in € submitted Mar 7th 2019, 17:42 by phNeutre | last Change Nov 2nd, 06:12 by phNeutre
Specs are approved by the manufacturer
