Multiple dual channel RG

Passive multiple dual channels with led indicator

Passive multiple dual channels (switched multiple) with LED indication of the selected channel : red=channel A, green=channel B. Led off, the signal is muted.
Customization option (+2€): If you wish, I can replace some switches (latching by default) by momentary (If you do not move the lever to the right or left, it returns to its central position. This creates effects or momentary actions!) on request, at your convenience depending on your use ;-)

  • 8 jack's IN/OUT
  • 2 channel's (A&B) & a central position "off"
  • Bicolore LED's
  • Latching switch's
  • Skiff friendly
  • Black or white panel
  • Choice to bicolore LED (blue/green or blue/red or red/green or red/yellow or white/red or blue/yellow)


alt text

alt text

More bicolore LED's available:
alt text alt text alt text alt text alt text

The price includes: module, screw M3 and connection cable. Excluding shipping costs !!
Manufactured by ph Neutre
Available as an assembled Module, no kit.
Tested and assembled by hand. All components are through, so all "ph" modules are repairable. Built to last ;-)

Also available in white panel :
alt text

To order, please contact me ( the terms of payment, delivery times and shipping costs, will be detailed by return mail.
The payment will be in euros (€) and can be done by paypal. Delivery possible in the world, please contact me (
Shipping costs :
alt text

  • 5 mA +12V
  • 0 mA -12V
  • 0 mA 5V
  • 25 mm deep

This Module is currently available.

$58 Price in € submitted Jan 27th 2019, 07:14 by phNeutre | last Change Feb 29th, 19:26 by phNeutre
Specs are approved by the manufacturer
