Triple Mode Ring Modulator

The Modulator offers 3 types of effects based on the standard Ring Modulator circuit.

Type 1: Ring Modulator - Outputs the sum and difference of the X and Y inputs.

Type 2: Floating Z Modulator - Outputs the sum and difference of the X and Y inputs summed with the ambient voltage within the circuit.

Type 3: Linear Amplitude Modulator - Outputs the sum and difference of the X and Y inputs summed with the carrier (Y) signal.

http://pittsburghmodular.com/mod/

  • 20 mA +12V
  • 20 mA -12V
  • ? mA 5V
  • 35 mm deep
  • Ø 3.57 (14 Votes) Average Rating

This Module is discontinued.
