4 HP
35 mm deep
Current Draw
20 mA +12V
20 mA -12V
0 mA 5V
$80 Price in €

This Module is currently available.

Double 'flavour' Utility

Two independent 4-to-1 mixers in different "flavors": the upper section is a averaged mixer, the lower section is a unity mixer. Polarity leds are really useful to check for waves.

Both mixers are useful for adding in a "quick and dirty" manner four signals. Unity mixer means that the input signals are not scaled and added togheter with the original amplitude. Averaged mixer means that the input signals are scaled by a 1/n factor, in our case of a 1/4 factor, then added togheter. It is obvious that if you feed a 10 Vpp signal in input 1 then you will get a 2.5 Vpp signal in output.

Built with high quality components this utility is ideal in any setup.
