Module is a 1U tile
This Module is a prototype or in a concept phase.
Quad random stepped voltage generator
1U version in 10HP of the 3U module: https://www.modulargrid.net/e/transient-modules-4r
The module follows the 1U Intellijel standard. (Probably will figure out something for 1U PulpLogic standard users too.)
The photo is a prototype, final production panel will be aluminium.
Price TBA.
Available: May 2019
The 4R is a quad random voltage generator. It generates two different random stepped voltages per input, each time a rising edge is sensed at TRIG1 or TRIG2. The inputs are independent so they can work at different clock speeds. As TRIG2 is normalled to TRIG1 it is also possible to get 4 random voltages with just one trigger. The voltage range of each pair of outputs can be set as unipolar (from 0V to +5V) or bipolar (from -5V to +5V).
Video of the 3U version:
