Dimensions
70 mm wide
115 mm high
Current Draw
? mA / ? V AC/DC
Price

This Pedal is currently available.

Vahlbruch Analog Chorus

Unlisted Chorus

Analog Chorus Pedal

The "Chorus" is an analog, hand-build, highly versatile modulation effect pedal and one of the finest chorus pedals in existence. Its unique circuit is carefully designed around a new-old-stock MN3007 BBD-IC to generate authentic shimmering chorus but also leslie-like sounds at a modern low electronic background noise level. Each unit is trimmed by hand to guarantee the desired and beloved homogenous modulation curve. This qualifies the pedal for any studio work and professional live performance. Controls include "Speed", "Depth" and "Mix". A constanly fshing LED indicates the modulation rate. Reduced "Speed" but high "Depth" seetings give you a really lush, watery and wide chorus sound, which can be perfectly intensity balanced using the "Mix" knob. Using the toggle switch you can also select a "Vibrato" (kill dry) mode. In this setting the "mix" knob controls the vibrato volume level. The vibrato ranges from subtle to very deep and intense. Unlike many other pedals, this "Chorus" does not alter your guitar signal phase and is therefore also perfectly suited for any parallel effect loops and stereo setups.

This pedal is equipped with our unique "MagTraB" switching technology:
Inside the button a magnet is integrated which position is measured by a sensor on the circuit board. If the button is now moved, e.g. if it is pressed downwards, the position of the magnet will also change. The sensor measures this change without any mechanical contact to the button and the information is send via a micro-controller to a gold-plated relay, which then does the actual audio signal switching.


submitted Nov 13th 2019, 20:50 by corcel2
