wave multiplier

wave multiplier

from serge-fans

Pro: Three different wave shaping sections. I was going to say 'audio wave shaping', but like everything else on the Serge, it can be used for CV also. Top section is a simple linear ac-coupled VCA with switchable mild clipping, handy for modulation or use as spare VCA. Middle section sounds 'something like' a very wild, resonant filter sweep, but that description doesn't do it much justice. Waveform fattener? If you look carefully through the archives on Analogue Heaven you'll find a thorough discussion on what the middle section does, in terms of how the waveform is 'folded over'. The bottom section is very versatile, regular and comparator-driven (pulse wave) outputs deliver woodwind type effects ranging from very subtle to 'bang you on the head.' Electrically, it's a variable full-wave rectifier with level compensation.

  • 75 mm deep

Module is available as a DIY project only.

This Module is a prototype or in a concept phase.

2 HP Waveshaper
submitted Oct 2nd 2016, 05:18 by APETECH!P | last Change Jul 31st 2017, 17:18 by loudestwarning
