Dimensions
2 U
Current Draw
? mA +15V
? mA -15V
? mA 5V
Price

This Module is a prototype or in a concept phase.

Modcan Quad LFO 61B - MU Panel

Unlisted LFO

Features:
12bit DAC, step free throughout 500Hz - 0.008Hz range
16 unique waves, see manual HERE for more details
All waves have some form of transformation available.
Four different Modulation destinations per LFO.
Three different Gate Modes per LFO.
Tempo Sync with divide is available to set LFO Rate using a clock.
Three Global Modes of operation: Normal, Quadrature and Rotate.
Three Modes for output wave polarity. +/-5V, 0-5V+, Inverted.
Memory storage to save user configuration.
User Interface:
This design uses a "paging" interface with four individual LFOs that are edited by a common set of 6 panel control knobs and 5 switches. The LFO EDIT knob selects one of four LFOs to edit. The knobs become "live" for that channel with the final edit settings stored to non-volatile internal EEprom memory. All settings are automatically restored on power up.

Three global modes of operation:
Normal: Each LFO is is edited individually. All Modulation routings and RESET options are controlled by panel switch settings and knobs and stored to memory.
Quadrature: Only one LFO is active but the other three outputs are 90,180,270 degrees out of phase with the primary out. This is great for quadraphonic panning using a 4VCA or Quad cross fading of four signals. Can also be used to sequence envelopes and a variety of other unique patches.
Rotate: This mode rotates the 4 LFOs to the 4 outputs A pulse/clock train on the GATE IN jack increments the outputs one jack to the right with each new pulse. The LFOs can be edited and all modulation routings and settings are retained. The Status LEDs remain static to help with editing. This can produce some truly chaotic patches with a vast array of modulation possibilities.

Modulation Destinations:
Each LFO has a CV input for modulation. The CV input is routed to the 4 modulation destination by the CV MOD switch. Destination are RATE, AMPLITUDE, TRANFORMATION and WAVE selection. All 4 destinations can be assigned and used simultaneously on all 4 channels.

GATE MOD functions:
A unique set of functions is available using the GATE MOD input. One GATE MOD setting is available per LFO.
None: Gate has no effect on channel
Reset: Gate high resets the LFO to start position 0
Hold: Gate high holds or freezes the current LFO wave state till goes low resuming oscillation from the hold state.
Sync:Very unique feature that synchronizes LFO Rate to an external clock or other LFO. This is a great method of keeping LFOs in sync with sequencers etc. In SYNC MODE the RATE knob is used to set the sync division from 1-10 of the input clock. Each LFO can be set to a different division value creating a very powerful rhythmic source that can used to generate a wide variety of synchronized modulation sequences and beat patterns. Also SYNC division is Voltage controllable allowing division variable to be modulated by external or other LFO channels for even more complex patterns.
