8 Step Assignable Voltage Sequencer

The Sequencer module is a compact, simple 8 step analog sequencer. It uses an external clock to cycle through 4, 6, or 8 steps. The output of the sequencer can be used control the pitch of an oscillator, modulate a filter, or manipulate any module with a CV input.

Complex sequences can be created using a combination of the Reset, Hold, and Add inputs. The Reset input can be used to create odd or variable length loops while Hold pauses the movement of the sequencer. Voltage from the Add input is summed with the voltage created by the Sequencer transcribing the output.

The Sequencer module also makes a great sub-octave generator. Clocking the Sequencer at audio rates using the square wave of an Oscillator turns the Sequencer into a sub-octave waveform generator able to produce 1 or 2 octaves below the frequency of the clock.

http://pittsburghmodular.com/sequencer/

  • 30 mA +12V
  • 30 mA -12V
  • 0 mA 5V
  • 25 mm deep
  • Ø 3.92 (26 Votes) Average Rating

This Module is discontinued.

$139
14 HP Sequencer
