ABY Box

PASSIVE ABY Line Selector Mini Pedal

• • • • • This unit can work without power. Power supply is for LED display only. * * * * *

Donner ABY BOX can be used to solve any number of complex audio switching problems. Use it to switch one input signal to either or both outputs, or it can also be used in the opposite direction. Route one signal to two outputs or two inputs to one output. Then choose A, B or A & B combined. LED's show you which signal is active.

LED indicator shows the working state
Flexible ABY box designed for a variety of scenarios

_____Features:

1.Convenient compact size

2.True bypass provide transparent tone,LED indicator shows the working state.

3.Signal path from A/B to Y, or from Y to A/B

4.DC 9V Jack:For power supply, use a 9-volt DC regulated by AC adapter, (plug polarity is positive on the barrel and negative in the center).This unit can work without power. Power supply is for LED display only.

_____Specifications:

1.Input: 1/4″Monaural Jack.
2.Output: 1/4″Monaural Jack.
3.Power Supply: DC 9V (Negative in the center ).
4.Working Current: 10mA.
5.Dimensions: 42x93.5x52mm
6.Material: Aluminum alloy
7.Weight: 220g
