Dimensions
120 mm wide
94 mm high
Current Draw
? mA / 9 V DC / Negative Center
Price

This Pedal is currently available.

Drunk Beaver Heavy Bat

Unlisted Distortion

Custom Rat with Blend and HM-2 EQ

Heavy Bat is a modern take on the classic Rat circuit with modifications. The pedal has a true bypass, and a rotary switch to select op-amp chips: NOS LM308, UD1408 (Soviet LM308 clone), LM358, and NOS 741. EQ section has two options: classic Rat filter tone control and three-band EQ similar to Boss™️ HM-2. In addition, you'll get the clean blend controls and 8 clipping diodes options, and two of them could be selected footswitch.

Controls:

Volume A/B - effect output level for each channel.
Filter - controls treble frequency response.
3-Band Active EQ - allows to boost or decrease the amount of treble, mids, and bass.
Tone toggle switch - allows selecting between classic Rat tone control and HM-2 style EQ.
Distortion - controls the amount of drive.
Mode rotary switches - 8 diodes options for each channel: LED (2 red LEDs, like Turbo Rat), none (raw op-amp clipping), Si (silicon 1N914 like classic RAT), Soviet Si (silicon KD541A), Hybrid (Germanium and Silicon diodes), MOSFET (BS170 transistor, like Fat Rat), Ge (NOS soviet D9 germanium diodes, like Your Dirty Rat), BAT (BAT85 Schottky diodes).
Op-Amp rotary switch - 4 chips modes: Classic (LM308), Soviet (UD1408), Modern (LM358), Ancient (741).
LED brightness trimmers - placed on the PCB trimmers allow you to adjust the status LED brightness for each channel.
Power Supply: 9V DC adapter (Boss-style negative center) not included. No batteries. They are bad for the environment 🌲.

Dimensions: 1590BB, 120mm x 94mm x 33mm

Lifetime Warranty - feel free to contact me if you have any troubles with a pedal!
