Kenton Pro 2000

CV to Midi interface

The PRO-2000 features 2 CV & Gate outputs and 6 fully programmable auxiliary CV outputs, 2 LFOs and 7 user memories. DIN Sync 24 and Arpeggio clock outputs are also fitted as standard. Backlit LCD display. The auxiliary outputs can also drive another 3 CV/Gate synthesizers if required. Optional extras: 1U rack-mount kit, KADI/Wasp or DCB port.

The PRO-2000 replaces the Pro-2, a converter which sold three thousand units and received unanimous acclaim both in the press and from customers. It has been used by Astral Projection.

Specifications
Two completely independent CV channels
Switchable V/Oct & Hz/V scaling options
Optional KADI or DCB port on its own channel
2 Independent LFO's assignable to any output
In-built LFOs synchronizable to MIDI clock
16x2 Character LCD display
Software set-up of tuning & scale
Multiple configuration memories
Internal power supply
LFO speed adjustable in real time
Built-in portamento adjustable in real-time
MIDI out with filtering to 'channelize' an omni on synth
Set-ups stored in non-volatile memory
Designed to control all types of mono-synth
V-trig (up to 15v) or S-trig (with or without pull-up)
Selectable note priority newest/lowest/highest
Adjustable pitch-bend range
Any MIDI channel can be selected
Set-ups stored in non-volatile memory
MIDI monitor mode - for easy MIDI troubleshooting
Sync 24 & Clock pulse outputs
Six software-assignable auxiliary outputs for MIDI Out and Thru sockets
