Dimensions
1 HP
20 mm deep
Price
$211 Price in €

Available as an assembled Module and as a DIY project.

This Module is currently available.

Waveshaper with 4 CV inputs

The build is great for beginners learning how to surface mount solder. All the passives are 0603 and there is only 1 IC with a pretty wide pitch.

To adjust the trim pots, input a saw wave. Measure the voltage of the signal going in to a channel and adjust the corresponding channel's trim pot so the output has the same voltage.

There is also a XWSX exapnder module in the make

https://github.com/themangoest/WSX


submitted Wednesday November 24, 09:56 by Delabelle
