Dimensions
6 HP
30 mm deep
Current Draw
26 mA +12V
26 mA -12V
0 mA 5V
Price
$224 Price in €

Available as an assembled Module and as a DIY project.

This Module is currently available.

Specs are approved by the manufacturer

VC Analog Kick drum voice

Kickall is a 6HP compact synth voice that features everything needed to make a big fat Kick sound: A stable VCO that tracks V/oct, a couple of VCAs, envelopes for volume and pitch and an aggressive wave shaper.
The module has been designed with a kick synthesis patch in mind: VCO to VCA with an envelope to open the VCA and another one to change VCO pitch. As addition a CV controlled waveshapper has been added to the VCO and an extra VCA at the end of the signal path to control the volume of the sound to act as kind of an accent.

Controls:
Continuous Sine to Square wave shaper. (Manual + CV)
Amp Decay.(+ CV)
Pitch Decay
Pitch bend
Tune (+CV)
Accent/Volume CV
Manual Trigger


Ø 4.28 (36 Votes) Average Rating
submitted Jan 22nd 2019, 17:57 by Befacosynth | last Change Jun 10th 2020, 16:31 by Befacosynth
