Dimensions
24 HP
35 mm deep
Current Draw
65 mA +12V
50 mA -12V
13 mA 5V
Price
$409 Price in €

Available as an assembled Module and as a DIY project.

This Module is currently available.

Specs are approved by the manufacturer

Dual Complex analog VCO

The CubuSynth Engine is a Dual analog VCO with wave shaping functions, internal modulations and a chaos generator. It is based around the 3340 chip and features 4 Waveforms + Wavefolder per VCO and 4 Modulated Outputs all simultaneously.

Specifications:

  • Size: 24HP / 121mm
  • Depth: 35mm (measured from the front panel)
  • Current Draw:
    +12V: +65mA
    -12V: -50mA
    +5V: 13mA

Key features:

  • 2 VCO cores (voices)
  • 4 simultaneous wave forms per voice + 4 Modulation Outputs
  • Wavefolder per voice
  • Pulse Width modulation
  • Linear and exponential FM inputs
  • 1 V/oct tracking stable over at least 8 octaves
  • Chaos generator with external clock input
  • Complex internal normalised modulations

https://cubusynth.com/products/cubusynth-engine
