Dimensions
6 HP
Current Draw
? mA +12V
? mA -12V
? mA 5V
Price

No info about availability.

GREEN SEQ PROTOTYPE

Unlisted Sequencer

Tiny 8 Step Sequencer

Tiny 8 (6hp) Step Sequencer Kit, Values are stored digitally with 8Bit Digital accuracy. To program you choose the desired Step with the Step Pot, then adjust the CV Value with the CV Pot. Values are stored permanently in an internal EEprom

The 10 LED Display shows the Step played, the Mode and the Step which is currently edited.

Mode determines wether the Sequencer moves
• forward
• forward and backwards (thus playing the outer Steps twice)
• cycles (plays the outer Steps once)
• randomly

The GREEN Sequencer can be synced by a Standard +5V Gate, internally to a RED LFO or completely tied to an external GREEN Controler.

CV Output is from 0…5V

http://www.flickr.com/photos/fcd72/sets/72157633372926895/


submitted May 2nd 2013, 20:58 by fcd72 | last Change Sep 7th, 13:40 by fcd72
