RED LFO PROTOTYPE

Digital Multi Waveform LFO

LFO Kit that performs the most common repetitive Modulation Tasks:
• Ramp Down
• Triangle
• Ramp Up
• Rectangle
• Sine
There are 3 Steps inbetween each Waveform, some kind of heavily quantized Morphing ;-)

• S/H Random Voltages
• Noise
• Offset Voltage

RED LFOs can by internally chained together to run multiple RED LFOs with different WaveForms locked to the same tempo - either phase synced or phase shifted - simply by turning the Tempo Pot full CCW to turn Sync Mode on. Phase shift in Sync Mode is then determined by the Tempo Pot.

Frequency is from 0,15 Hz to 16,5 Hz for the LFO Wavforms. Voltages go from -10 to +10V.

The Module contains a +5V PSU that can - besides powering the Module -deliver (just set a Jumper) +5V up to 200mA to your Rails and power other Modules. Or it can be left blank if you have a +5V rail on your Rails

http://dmachinery.wordpress.com/2013/04/30/107/
