Dimensions
2 HP
20 mm deep
Current Draw
Module does not draw current
Price
$40 Price in €

This Module is currently available.

Three-mode Dual Passive Low Pass Gate by kNoB technology

DP LPG is a passive device that does not require power, resistor optocoupler based, or alternative name Vactrol.
This device, without supplying voltage to the control input, almost does not pass the signal, when the control voltage is applied, it changes the amplitude and opens like a VCA amplifier, with a characteristic curve corresponding to the resistor optocoupler, which has a small signal release (LPG envelope), and the memory effect of a resistor optocoupler.
Technical specifications
Normally closed gate / VCA
Noise transmission is dark -75db (+ - 10%) with an input signal Sine 1kHz + -5Vp-p in the mode without
cutting the high frequencies.
Since this LPG is passive, the minimum voltage for opening is about 1.8V-2V
The maximum CV source current required for maximum opening is 3mA, operating is less than 1mA
Our LPG use matched pairs of opto-resistors and LEDs to provide excellent speed performance. The
maximum frequency of distinguishable modulation of one signal by another signal is 10 kHz.

User manual PDF link - https://vk.com/doc-67411427_594667874

For order: write to knobtechnology@gmail.com

Introducing:

Demo:

Low Pass Gate LPG. How to Use. Ideas for making patches with LPG.
