Voltage Controlled Oscillator

A compact Voltage Controlled Oscillator designed for generating SINE waves, Variable wave-SHAPEs, SUB-Octaves, Oscillator SYNC and Linear FM in the analog domain. The Sub-Timbral Oscillator is the more subtle and melodic friend to the DPO's complex harmonic lattice.

Triangle Core with outputs for SINE, SUB and Variable SHAPE

Unique Variable SHAPE circuit ripples Even and Odd harmonics for subtle timbral shifts

Linear FM input with Depth control

EXPOnential input for deep FM, SYNC sweeps or Transposition of sequences

SUB-Oscillator yields max bass

S-Gate input for gating or sync of SUB-Osc. independent of other outputs

Hard SYNC circuit which combined with Linear FM and Variable SHAPE yields harmonically rich sounds

Pairs well with the MMG or Optomix

http://www.makenoisemusic.com/modules/sto

  • 40 mA +12V
  • 30 mA -12V
  • 0 mA 5V
  • 30 mm deep
  • Ø 4.39 (88 Votes) Average Rating

No info about availability.

$199
8 HP Oscillator
submitted Nov 18th 2013, 16:23 by makenoise | last Change Nov 14th 2017, 18:45 by makenoise
Specs are approved by the manufacturer
