Dimensions
22 HP
12 mm deep
Current Draw
? mA +12V
? mA -12V
? mA 5V
Price
$391 Price in €

This Module is currently available.

Noisy Oscillator (photo plate)

Unlisted NoiseOscillator

Noisy Oscillator

Modor's Noisy Oscillator module is and oscillator that mixes two signals: a 'regular' wave (sawtooth/square/triangle) and a 'tonal noisy' wave. This adds a special noisy layer over the sound, that adds 'air', grit or dirt, depending on the combinations you make. The MOD parameter acts on the noisy waveforms:

Sonar Noise: a white noise filtered by a resonant bandpass filter, with 1V/oct tracking of the filter frequency. The MOD parameter controls the resonance.
Wind Noise: white noise filtered by a comb filter, with 1V/oct tracking of the base frequency (delay). The MOD parameter controls a 6dB/oct hipass filter.
Arcade Noise: LFSR noise source as can be found on the SID soundchips (Commodore) or Sega Arcade games. The MOD parameter controls again a 6dB/oct hipass filter.

The noisy wave can be set equal, or 1 or 2 octaves above the regular wave.

The module has two voices, with their own set of CV and output connectors. This can be used to play in a full 2-voice polyphony, or in a 2-voice unison. The outputs can be separate, using both output connectors, or mixed, using only the connector of the second voice.

Next to the 1V/oct pitch CV, the module offers CV control over pitch (FM), the MOD parameter and the sound level:

FM CV: pitch control normalled to 0V, attenuated with the FM knob (+ and -). This allows for Frequency Modulation up to the lower audio range. It's of course a digital module, so higher frequencies can start inducing aliasing and digital artefacts.
MOD CV: CV control for the MOD parameter, normalled to 0V and attenuated with the CV AMT knob (+ and -).
LEVEL CV: CV control for the sound volume, normalled to 7.5V. With this CV control you can omit an external VCA stage if you want.

The CV signals of the second voice (upper row of connectors) are always normalled to the signal of the first voice (lower row), so you can use a single LFO for some FM vibrato or tremolo on both voices, for example. Only the V/oct connector of the second voice is normalled to the first voice with an extra addition of a fixed voltage that can be set using a trimmer at the backside of the module. This way you can use the 2 voices to play in unison with a fixed pitch separation you can set on the backside.ies.

http://modormusic.com/eurorack.html


submitted Mar 1st 2020, 03:08 by Precarious
