DIY Voltage Offset/Scaler

DIY CV Offset/Scaler module based on a quad OpAmp

Based on Stereoping circuit design found here: http://www.stereoping.com/eurorack-diy-offset-scaler/?lang=en

Can offset and attenuate/amplify (up to supply voltage less ~1.5V).

E.g. 0-5V from SQ-1 sequencer can 'play' the Phonogene's 'Slide' CV in which requires ~+/-8V for full range.

Bipolar LEDs to indicate relative input and output voltage level.
Also includes an inverted output.
With no input, generates a fixed voltage.

  • 12 mA +12V
  • 12 mA -12V
  • 0 mA 5V
  • 25 mm deep
  • Ø 3.00 (1 Votes) Average Rating

Module is available as a DIY project only.

No info about availability.

$35 Price in €
Unlisted 4 HP AttenuatorPolarizer
submitted Oct 4th 2015, 01:51 by Oblivion | last Change Oct 6th 2015, 00:35 by Oblivion
